Overview |
| 동축 2웨이 드라이버를 갖춘 125와트 보스 프로페셔널 DesignMax DM6C 스피커는 풍부한 저음과 명확하고 이해하기 쉬운 고음을 제공하며, 상업적 사운드 설치와 잘 어울리는 프리미엄 미적 요소를 제공합니다. DM6C는 6.5인치 우퍼와 1.25인치 동축 트위터가 장착된 분산 정렬 시스템을 특징으로 하며, 59Hz – 20kHz의 주파수 범위를 제공합니다. 천장에 설치되는 DM6C는 QuickHold 장착 팔을 통해 쉽게 설치할 수 있습니다. |
FEATURES | ||
| Applications다양한 용도를 위해 설계되었습니다.
| |
SPECS | ||
Technical Specification | ||
COMPLIANCE | ||
Safety Agency Ratings UL-1480A, S5591/ UL Listed, in compliance with UL2043 for plenum-space installation, NFPA70 & NFPA90-A, CE compliant | ||
PHYSICAL | ||
Colors Black (RAL 9005), white (RAL 9003), paintable | Enclosure Material Engineered-plastics front baffle with integrated steel-formed backcan | |
Grille Magnetically attached perforated steel, powder-coated finish, paintable, with safety tether | Environmental Indoor only | |
Ceiling Cutout 11.5 in (292 mm) | Suspension/Mounting (3) QuickHold spring-loaded mounting arms, (3) safety cable attachment points | |
Logo Rotatable, removable | Operating Temperature Range 0 °C to 50 °C (32 °F to 122 °F) | |
Product Dimensions (H×W×D) 14.0 in × 9.4 in (356 mm × 239 mm), loudspeaker diameter × depth / 11.3 in × 8.8 in (287 mm × 223 mm), backcan diameter × depth | Net Weight 14.3 lb (6.5 kg), loudspeaker with grille (single) / 1.8 lb (0.8 kg), tile bridge (single) | |
Shipping Weight 39.1 lb (17.7 kg), pair | ||
PERFORMANCE | ||
Frequency Range (-10 dB) 59 Hz – 20,000 Hz | Coverage, Horizontal 120° conical | |
Calculated Maximum SPL @ 1 m 109 dB | Nominal Impedance 8 Ω (transformer bypassed) | |
Power Handling, long-term continuous 125W | Power Handling, Peak 500W | |
Recommended Signal Processing Not required, Bose Professional EQ voicing and SmartBass processing available | Sensitivity (SPL/1 W at 1 m) 88 dB | |
Transformer Taps, 100V 5, 10, 20, 40, 80 W, bypass | Transformer Taps, 70V 2.5 W, 5 W, 10 W, 20 W, 40 W, 80 W, bypass | |
Coverage, Vertical 120° conical | ||
TRANSDUCERS | ||
Crossover 1.7 kHz, passive 2-way crossover | Driver Protection Recommended high-pass protection 60 Hz with recommended 24 dB/octave filter | |
High-Frequency 1 × 1.25 in (32 mm) neodymium dome tweeter, coaxially mounted | Low-Frequency 1 × 6.5 in (165 mm) woofer | |
VIDEOs | ||
 |  |  |
Product codes | ||
829679-0110 DESIGNMAX DM6C PAIR BLK 829679-0210 DESIGNMAX DM6C PAIR WHT | 829679-0120 DESIGNMAX DM6C PAIR BLK (NEW) 829679-0220 DESIGNMAX DM6C PAIR WHT (NEW) | |
Included in Packaging | ||
(1) cutout template (2) DesignMax DM6C loudspeakers (2) grilles (2) tile bridges (1) installation guide | ||
