Overview |
Bose Professional PowerMatch PM8500N 구성형 프로페셔널 파워 앰프는 고정 설치형 음향 강화 시스템을 위해 콘서트급 사운드를 제공하며, 높은 확장성과 구성 유연성을 갖추고 있습니다. 이더넷 기반 네트워크를 통해 설정, 제어, 모니터링이 가능하며, 확장 슬롯을 통해 선택 사양의 디지털 오디오 액세서리 카드 입력을 지원합니다. 전면 USB 포트를 사용하면 단일 앰프를 PC와 직접 연결하여 설정할 수 있습니다. PowerMatch 앰프는 Bose Professional의 다양한 기술을 적용하여, 탁월한 성능·효율성·설치 편의성을 모두 갖춘 독창적이고 신뢰성 높은 설계를 구현했습니다. |
FEATURES | ||
| Applications다양한 용도를 위해 설계되었습니다:
| |
SPECS | ||
Technical Specification | ||
AMPLIFICATION | ||
Channel Separation (Crosstalk) > 65 dB, adjacent channels at 1 kHz | Gain, High-Impedance 42 dB | |
Gain, Low-Impedance 36 dB, Mono mode / 42 dB, V-Bridge mode / 36 dB, I-Share mode / 42 dB, Quad mode | Maximum Peak Power, Symmetrical 1000 W | |
SNR > 102 dB (1 dB below rated power, A-weighted) | Frequency Response 20 Hz – 20 kHz (±0.5 dB) at 1 W | |
Number of Channels 8 | Power Class Class D | |
Rated Power, Symmetrical 450 W per channel at 2 Ω / 500 W per channel at 4 Ω / 300 W per channel at 8 Ω | THD+N < 0.4% at 1 W (20 Hz – 20 kHz) | |
AUDIO INPUTS, ANALOG | ||
Input Channels 8 balanced, line | Connectors (8) 3-pin Euroblock | |
Input Impedance > 100 kΩ | Maximum Input Level 24 dBu at 24 dBu sensitivity | |
Sensitivity 0 dBu, +4 dBu, +12 dBu, +24 dBu, selectable | ||
AUDIO INPUTS/OUTPUTS, DIGITAL | ||
Channels Expansion card-dependent | Connectors Expansion card-dependent | |
Type 6-pin Euroblock | ||
AUDIO OUTPUTS, ANALOG | ||
Channels 2–8, configurable | Connectors (2) 8-terminal block, 7.62 mm | |
COMPLIANCE | ||
EMC This product meets all EN55103-2 immunity requirements for E2 electromagnetic environment. | ||
ELECTRICAL | ||
Current Draw, Idle 0.3 A (standby) or 1.3 A (awake) at 120 VAC, 60 Hz / 0.1 A (standby) or 0.5 A (awake) at 230 VAC, 50 Hz | Current Draw, Inrush 15.4 A at 230 VAC, 50 Hz | |
Mains Connector IEC 60320-C20 inlet | Mains Voltage 100–240 VAC (±10%), 50/60 Hz | |
Protections High temperature, DC, short circuit, high frequency, voltage limiter, current limiter, inrush current, mains circuit breaker | AC Power Consumption 31 W standby (idle), 176 W awake (idle), 1789 W maximum | |
GENERAL | ||
Software Applications ControlSpace Designer 3.2 or later (Windows) | Computer Interface Connection USB Type-B, RJ-45 (Ethernet, 100 Mbps) | |
Notification Outputs (1) 3-pin Euroblock | ||
INDICATORS AND CONTROLS | ||
Controls, Front Panel (1) navigation soft key, (5) menu soft keys, (1) scroll/select knob (rotary/push) | Controls, Rear Panel POWER SWITCH – ON/OFF AC power switch | |
LED Status Indicators (1) input signal LED, (1) input clip LED, (1) output limit LED, (1) fault LED | ||
INTEGRATED DSP | ||
Delay 3 s | Equalization Input: 8-band parametric EQ (±15 dB), notch, shelving, high-pass, low-pass / array EQ (ArenaMatch) / band-pass crossover / loudspeaker: 9-band parametric EQ (±15 dB), notch, shelving | |
Crossover Types Butterworth, Bessel, or Linkwitz-Riley, up to 48 dB/octave | A/D and D/A Converters 48 kHz / 24-bit | |
Audio Latency < 0.95 ms, analog input to analog output | DSP-Enabled Yes | |
Limiters Peak voltage, RMS voltage, clip | Presets Bose Professional loudspeaker presets | |
Processing Functions Input EQ, array EQ, loudspeaker EQ, peak voltage limiter, RMS voltage limiter, delay, band-pass, matrix mixer | ||
PHYSICAL | ||
Colors Black | Cooling System Microprocessor-controlled, variable-speed fans, front to rear airflow | |
Suspension/Mounting Rack-mounting | Operating Temperature Range 0 °C to 40 °C (32 °F to 104 °F) | |
Product Dimensions (H×W×D) 3.5 in × 19.0 in × 20.7 in (88 mm × 483 mm × 525 mm) | Net Weight 28.4 lb (12.9 kg) | |
Rack Spaces 2 | Shipping Weight 34.5 lb (15.7 kg) | |
 |  |  |  |  |
 |  |  |  |  |
Product codes | ||
343546-1110 120V US 343546-4110 230V EU | 343546-2110 230V AU 343546-5110 230V UK | 343546-3110 100V JP |
Included in Packaging | ||
(2) 8-pin Euroblock connectors (4) shorting jumpers (9) cable ties (1) installation guide (9) 3-pin Euroblock connectors (1) IEC power cord (1) PowerMatch PM8500N | ||
