색상 : Black, White
Overview |
| 동축 2웨이 설계를 가진 125와트의 보스 프로페셔널 DesignMax DM6PE 스피커는 풍부한 저음과 명확하고 이해하기 쉬운 고음을 제공합니다. 또한 상업용 음향 설치를 보완하는 프리미엄 미학을 갖추고 있습니다. 이 스피커는 6.5인치 동축 우퍼와 1.25인치 트위터가 장착된 분산 정렬 시스템을 특징으로 하며, DM6PE 팬던트 스피커는 62 Hz – 20 kHz를 제공합니다. DM6PE는 IP55 등급의 야외용 팬던트 스피커로, 세련되고 매력적인 외관을 위한 매립형 단일 지지 시스템을 특징으로 하며, 검정색 또는 흰색으로 제공됩니다. |
FEATURES | ||
| ||
SPECS | |||
Technical Specification | |||
COMPLIANCE | |||
Safety Agency Ratings UL 1480A, UL 2239 for suspension cable, NFPA 70 & NFPA 90A, CE-compliant | |||
PHYSICAL | |||
Colors Black (similar to RAL 9005), white (similar to RAL 9003), paintable | Enclosure Material Engineered plastics, highly UV fade-resistant | ||
Environmental Outdoor per IEC 529 IP55 (suitable for use outdoors in wet locations), includes aluminum grille to prevent red corrosion and weather resistant input cover | Grille Perforated steel, powder-coated finish | ||
Ingress Protection IP55 | Logo Rotatable, removable | ||
Operating Temperature Range -25 °C to 65 °C (-13 °F to 149 °F) | Product Dimensions (H×W×D) 12.1 in × 14.8 in (308 mm × 375 mm), loudspeaker diameter × depth | ||
Suspension/Mounting 1 suspension attachment point, 1 safety cable attachment point | Net Weight 12.5 lb (5.7 kg), single | ||
Shipping Weight 33.1 lb (15.0 kg), pair | |||
PERFORMANCE | |||
Frequency Range (-10 dB) 62 Hz – 20,000 Hz | Coverage, Horizontal 115° conical | ||
Calculated Maximum SPL @ 1 m 110 dB | Nominal Impedance 8 Ω (transformer bypassed) | ||
Power Handling, long-term continuous 100 W | Power Handling, Peak 400W | ||
Recommended Signal Processing Not required, Bose Professional EQ voicing and SmartBass processing available | Sensitivity (SPL/1 W at 1 m) 89 dB | ||
Transformer Taps, 100V 5, 10, 20, 40, 80 W, bypass | Transformer Taps, 70V 2.5 W, 5 W, 10 W, 20 W, 40 W, 80 W, bypass | ||
Coverage, Vertical 115° conical | |||
TRANSDUCERS | |||
Crossover 1.7 kHz, passive 2-way crossover | Driver Protection Recommended high-pass protection 48 Hz with recommended 24 dB/octave filter | ||
High-Frequency 1 × 1.25 in (32 mm) neodymium dome tweeter, coaxially mounted, weather-treated | Low-Frequency 1 × 6.5 in (165 mm) woofer, weather-treated | ||
VIDEOs | |||
 |  |  |  |
Product codes | |||
841168-0110 DESIGNMAX DM6PE PAIR BLK 841168-0210 DESIGNMAX DM6PE PAIR WHITE | 841168-0120 DESIGNMAX DM6PE PAIR BLK (NEW) 841168-0220 DESIGNMAX DM6PE PAIR WHITE (NEW) | ||
Included in Packaging | |||
(4) cable ties (2) suspension cables, 15.0 ft (4.5 m) each (1) weather-resistant input cover | |||
